NanaWall HSW66 Wood Framed Single Track Sliding System

The NanaWall® HSW66 is a wood-framed single track sliding system designed to provide an opening glass wall or storefront with any custom panel size.‎ Different panel widths are possible.‎ An end-panel can be a swing-panel hinged to a side jamb or in the SwingSlide option, a swing panel can be a middle panel that is hinged from a sliding panel.‎ Swing-panels are single acting but can be either inward or outward opening.‎ Possible configurations and stacking bay options are virtually limitless.‎ The aluminum head jamb thickness is 2 9/16" (65 mm).‎ The wood side jamb thickness is 2 5/8" (66 mm).‎ The HSW66 stiles and rails of sliding panels with interlocking tongue-and-groove profiles have a nominal panel thickness of 2 5/8" (66 mm).‎ Standard woods are Sapeli Mahogany, European Pine (Keifer) or Meranti, other woods are also available.‎ Further info from manufacturer on HSW66 NanaWall
