Pilosio MULTIDIREZIONALE MP - Многофункциональные строительные леса

Pilosio MP Multidirectional scaffolding is a very flexible system with great modularity and high capacity.‎ Great versatility thanks to rosettes welded to vertical uprights every 50cm that allow 8 independent connections in 360°.‎ The bolt-free connection (wedge-head and rosettes) allows quick, easy and very safe assembly and dismantling.‎ MP system suits a wide range of applications from construction to industrial maintenance, shipyards, entertainment venues, facade applications and restoration.‎ Advantages Easy handling Quick and easy assembly with only one hammer and level Enlarged working area width Wide range of system accessories to meet any need Extremely adaptable and robust Flexible angle set up due to small and large connecting openings Wide range of spans available Technical Data Load capacities: MP 83: 150 daN/m² ; MP 115: 300 daN/m²; Up to 8 ledgers/diagonals per level Height intervals at every 50 cm Steel finishing : hot deep galvanized Steel tubes Ø 48.‎3 mm with wall thickness 3,2 m for standards and 2.‎3 mm for diagonals and ledgers Further info from manufacturer on MULTIDIREZIONALE MP Pilosio
