DQG - Diquigiovanni DQG HST 85 PVC lift and slide door
DQG HST 85 is the PVC profile, available in a wide range of colours and finishes, which allows for lift-up sliding doors with a modern design.
As standard, 27 mm threshold in insulating resin.
On request, it is possible to request
the PREMIUM version with insulated sashes and 61 mm threshold in foamed resin to be recessed into the floor;
the PANORAMIC version with an almost concealed fixed sash (32 mm) that increases the glass surface area and provides natural light to the rooms.
System
frame 197x63 mm
3 panes
2 seals
glass thickness up to 51 mm
Acoustic Insulation
Rw= up to 45 dB
Values for standardised sample window (3600 x 2300 mm)
Thermal Insulation
Uf=1,30 W/m²k
Uw=1,24 W/m²k (with Ug=1,00 W/m²k)
Uf=1,10 W/m²k
Uw=1,16 W/m²k (with Ug=1,00 W/m²k)
Values for sample window (1480 x 2180 mm)
Possible Types
lift and slide door
