CERO II - Раздвижное окно

The thermally insulated cero II system with double glazing and a panel depth of 52 mm is a great choice for buildings with low thermal insulation requirements in combination with a flush-mounted floor track, for use in commercial premises or as a partition.‎ It is also possible to brace the profiles with steel inserts – making cero II ideal for use with increased structural requirements.‎ PROFILE SYSTEM - Thermally insulated aluminium profile system in all-glass look - Flush-mounted running tracks and guide rails built into the system.‎ - Thermal break made of fibreglass-reinforced polyamide - Ventilation and concealed drainage of the bottom glass rebate in accordance with DIN 18545 “Glazing guidelines for double glass” SIGHT LINES - Frame: 0 – 75 mm - Panel: 34 mm - Panel joint: 34 mm - Frame building depth: 71 – 243 mm - Panel building depth: 52 mm SEALING SYSTEM - High degree of impermeability thanks to the use of several sealing levels - Dry glazing GLAZING - Glass thicknesses 30 – 36 mm - Self-cleaning glass available - Can handle glass discrepancies of up to 5 mm in width and height - Security glass VERSIONS - The panels run on floor tracks - Slide to left or right - Forend reversed and offset - Floor track flush and compliant with DIN 18040 “Accessible apartment” FITTINGS - Fittings partly concealed in profiles - Replaceable carriages - Sealed-bearing, stainless steel carriages - Stainless steel running track for many years of reliable running - Running track kept clean thanks to protruding moulded pieces in the panel - Sturdy SL designer handles - Panel locking with 24 mm latch bolt - Optional magnetic sensors for lock monitoring OPTIONS - Multi-track systems available - Suitable for use in a variety of corner situations - Electric panel drive available - Broken glass alarm available - Functional glass as sound insulation and protection against burglary and impact - Connection to higher-order control and monitoring systems - Electromechanical locking element - Built-in insect screen ENVIRONMENT - Certified disposal in accordance with DIN EN ISO 14001:2005 - Sustainable manufacturing - Internal production control Further info from manufacturer on CERO II Solarlux
