Alumil SMARTIA M14500 Patio door

M14500 consists of a low-cost proposal for sliding systems without thermal break.‎ Supports all known sliding typologies and offers an alternative to those who pay attention to the investment cost.‎ - Sash width of 32 mm - Double glazing up to 20 mm thickness and sash weight up to 120 Kg - Stainless steel rails offering smooth and easy scrolling of the sashes - One or two points locking hardware for a higher security level - Ideal proposal for old frames replacement especially in case of pocket constructions with limited blank in the wall PROFILE CHARACTERISTICS Frame width     78,2 mm Sash width 32 mm Minimum visible height of construction  1110,1 mm Sash mechanism weight limit 80 Kg Maximum glass thickness 20 mm Cross section thickness up to 1,4 SYSTEM CHARACTERISTICS Type of system Uninsulated  Uf from 6,46 W/m2K Exterior aesthetics Curved Sliding Type Slide Type of thermal insulation - Mechanism GU 934 Typologies Double horizontal sliding sash Triple horizontal sliding sash Two double horizontal sliding sashes with meeting point Corner construction with doublehorizontal sliding sash Corner construction with sliding sash into wall cavity Single sliding sash into wall cavit Certifications Air permeability – Watertightness – Resistance to wind load ΕΚΑΝΑL Further info from manufacturer on SMARTIA M14500 Alumil
