Alumil SMARTIA S350 Patio door

S350 is a new approach in sliding systems in full accordance with the modern architectural trends for soft and straight lines and considerably less visible aluminium frame.‎ High levels of thermal insulation combined with a great variety of innovative design solutions, make S350 the ideal solution for building modern residences as well as for frames replacements.‎ Innovative design and minimal aesthetics Soft, straight lines and up to 50% reduction of the visible aluminium frame Profile sturdiness and strength that easily cover the most demanding customers’ requirements Undoubted construction flexibility and ease High level of thermal insulation and outstanding quality Unique performance in water/air tightness in its category Ideal solution for frames replacements.‎ PROFILE CHARACTERISTICS Frame width     92 mm Sash width 35 mm Minimum visible height of construction  116,1 mm Sash mechanism weight limit 120 Kg Maximum glass thickness 24 mm Cross section thickness up to 1,6  SYSTEM CHARACTERISTICS Type of system Insulated  Uf From 2,4 W/m2K Exterior aesthetics Flat Sliding Type Slide Type of thermal insulation 24 mm polyamide Mechanism GU Inline, Bezault Typologies Double horizontal sliding sash Triple horizontal sliding sash Two double horizontal sliding sashes with meeting point Single sliding sash into wall cavit Double sliding sash into wall cavity with meeting point One sash sliding door with fixed panel CERTIFICATIONS Thermal Insulation IFT Rosenheim Air permeability – Watertightness – Resistance to wind load –  Functional check IFT Rosenheim Sound reduction AUTH Further info from manufacturer on SMARTIA S350 Alumil
