CONDOR - Система самозаглубления MA

Trench shoring is a provisional system aiming at supporting excavation walls inside which works are performed relating to sewage and pipeline of several types.‎ The European standard EN 13331-1/2 (and the italian D.‎lgs 81/2008) requires that, for excavations deeper than 1.‎50 m, reinforcements must be applied in order to prevent excavation walls from collapsing and avoid any danger for the operators.‎ CONDOR trench shoring systems are designed to meet high safety standards during excavations, thus saving time and money.‎ CONDOR offers two types of trench shoring, depending on the characteristics of the excavation and the soil: - MA System - GD600 SystemTrench CONDOR developed the MA trench shoring system, in order to guarantee maximum safety in trenching works up to maximum 4.‎40 m depth with soil of good consistency.‎ The system is used already assembled in the job site.‎ The MA trench shoring is made up of a standard 3.‎00m x H=2.‎00m panels, connected with adjustable spacers.‎ If excavation is deeper, it’s possible to install elevation elements.‎ By combining elevation panels to the standard ones the maximum depth reachable is 4,40m in absolute safety.‎ The system is designed to withstand a pressure up to 22 kN/sqm Further info from manufacturer on MA self-sinking system Condor
