EKINEX EKINEX® EK-FF1-TP 16-fold binary output / 8-fold blind actuator

The Ekinex® EK-FF1-TP binary output / blind actuator allows to command 16 groups of loads or control 8 drives for motorised blinds independently.‎ The device is fitted with membrane pushbuttons for manual command (even in the absence of bus power) and LED’s for status indication; a pushbutton allows to switch between automatic and manual operation modes.‎ The device integrates a KNX bus communication module and is realized for mounting on a standard 35 mm DIN-rail.‎ The device is supplied by the KNX bus and requires an additional 230 Vac power supply to operate.‎ Technical data: • Voltage auxiliary 100-230 Vac 50/60 Hz • Voltage control section 30 Vdc by KNX bus • Current consumption from bus < 10 mA • Power on bus < 240 mW Outputs: • Number: 16 or 8 independent channels (depending on device use) • Nominal voltage (Un): 100-230 Vac 50/60Hz • Nominal current (In): max 16 (10) A (both @100Vac and @230Vac) • Max.‎ switched power: max 4000 VA @250Vac Delivery: Delivery includes a terminal block for connection to the bus.‎ Further info from manufacturer on EKINEX® EK-FF1-TP EKINEX
