IVAR MULTIMIX

The MULTIMIX system is a mixing and booster substation that allows fluid at different temperatures to be sent to each thermal zone through distribution kits, made independent of the pressure balancer integrated in the main manifold.‎ Its extraordinary compactness facilitates installation under the boiler and in small spaces.‎ MULTIMIX consists of the manifold/separator and direct or mixer kits, which can be combined according to specific needs.‎ Pre-assembled configurations are also available with polypropylene insulation shells and/or built-in metal cassette.‎ MULTIMIX can also be supplied from the side connections, and allows two or more manifolds to be connected to each other.‎ The system, unlike MULTIMIX-C, allows the temporary or permanent exclusion of the separation function hydraulic, useful for example in the case of connection to a buffer tank.‎ Max primary flow rate: 3000 l/h Max flow rate per kit: 1700 l/h PLUS - Hydraulic separator integrated in the main manifold - Possibility of supply from top/bottom, right/left - Compact, modular and expandable - Available in pre-assembled configurations - Suitable for heating and cooling FOCUS hydraulic separation - The manifold integrates hydraulic separation, a fundamental function in systems with several pumps that can work simultaneously.‎ - The hydraulic separator can be intercepted even when the system is running by means of a shutter that can be operated from the outside.‎ - The separator creates a hydraulic short circuit that makes the circulators, installed on the secondary and primary, totally independent of each other.‎ COLLECTOR/SEPARATOR - 3 functions: - Supply manifold - Return manifold - Hydraulic separator (can be excluded) - Connections to the primary from the right, left, top or bottom - Can be supplied by several heat generators at the same time - 2 or 3 zones, expandable with additional side-connected module MIXING AND DISTRIBUTION KIT - 3-way piston mixing valve and secondary bypass - Possibility of fixed point or climatic regulation - Intercepting pump and simplified installation thanks to telescopic connection - Safety thermostat, thermometers, non-return valve DIRECT DISTRIBUTION KIT - Intercepting pump and simplified installation thanks to telescopic connection - Thermometers, non-return valve Compact MULTIMIX / MULTIMIX-C sub-boiler distribution systems The MULTIMIX and MULTIMIX-C systems allow the fluid to be sent at different temperatures to each thermal zone thanks to the distribution and recovery kits, which are independent of the pressure balancer integrated into the main header.‎distribution and recovery kits, made independent by the pressure balancer integrated into the main header.‎ Their extraordinary compactness makes them easy to install under the boiler and in confined spaces.‎ MULTIMIX and MULTIMIX-C are both made up of the manifold-separator and direct or mixing valve kits, which can be combined according to specific requirements.‎ Pre-assembled configurations are also available, with insulation shell and/or flush-mounted metal box.‎ MULTIMIX can also be supplied via the side connections and allows two or more manifolds to be connected to each other.‎ Unlike MULTIMIX-C, the system allows the temporary or permanent exclusion of the hydraulic separation function, useful for example when connected to an inertia accumulator.‎ Further info from manufacturer on MULTIMIX IVAR
