Vortice MEX 120/5" LL 1S T Aspirator

- Plastic resin construction resistant to impact and ageing caused by exposure to the sun ("UV resistant").‎ - Nominal diameter 120 mm - AC motor with shaft mounted on a ball bearing support, directly coupled to a plastic helicocentrifugal impeller.‎ - Maximum flow rate 175 m3/h - Version equipped with an electronic card that allows delayed shutdown; the delay can be programmed in a range from 3' to 20' at the time of installation.‎ - Equipped as standard with a butterfly check valve to prevent unwanted air re-entry when switched off.‎ - Degree of protection IP45, which guarantees the possibility of installation in Zone 1 of the bathroom according to international standard IEC 603647.‎ - IMQ-certified safety.‎ TECHNICAL DATA AND PERFORMANCE Max.‎ absorbed current at max.‎ speed (A) 0.‎095 Nominal diameter of ducting (mm) 120 Frequency (Hz) 50 Protection class IP 45 Insulation class II° Weight (Kg) 0.‎77 Max.‎ absorbed power at max.‎ speed (W) 13 (W) 13 Max.‎ ambient temperature at max.‎ continuous operation (°C) 50 Voltage (V) 230 Max.‎ flow rate at max.‎ speed (l/s) 48,6 Max.‎ flow rate at max.‎ speed (m³/h) 175 (m³/h) 175 Sound power level Lw [dB(A)] max vel 52,8 Max pressure at max speed (mmH2O) 5 Max pressure at max speed (Pa) 49,04 Sound pressure Lp in free field [dB(A)] 3 m max speed 32,3 RPM max 2075 Stylish Axial Fan by Vortice.‎ High performance Quiet - 26.‎9dBA eNERGY sAVING - 0.‎36 w/l/s Stylish Design
