Twin Systems PC 90 Shutter
Profiles enabling the construction of single- or multi-wing Persiane shutters with a 90° cut-off effect.
Extruded profiles Alloy: ENAW 6060 (EN 573 - 3)
Delivery condition: T5 (EN 752 - 2)
Size and thickness tolerances: EN 755 - 9 EN 755 - 9
Type of sealing: Double rebate
Rustica
Fixed frame: mm. 55 x 76
Wall rebate: mm. 40
Movable frame: mm. 51 x 76
Slat mechanism: fixed or pivoting with 35 x 14 groove
Accessories: type Rustico
Frame and sash corner joint: with tubular brackets mm.10.4 x mm. 42.2 or alternatively 15.2 mm. x 29.2 mm.
Classic
Fixed frame: mm. 55
Wall reveal: mm. 40
Mobile frame: mm. 51 x 80
Slat mechanism: fixed or pivoting with groove 35 x 14
Accessories: with unified chamber space mm. 14
Corner joint frame and sash: with tubular brackets mm.10.4 x mm. 42.2 or alternatively 15.2 mm x 29.2 mm.
