TBK THERMOBLOK® – Singolo BASIC Monoblock window

THERMOBLOK® – Singolo BASIC is a thermal insulation monoblock designed to accommodate individual windows and doors, engineered to ensure high thermal insulation performance, continuity of the building envelope and precise, rapid installation of the window or door.‎ Fully made to measure, it can be configured for the installation of the window or door either flush with the internal wall or centred, adapting to specific design requirements.‎ The window frame is recessed on three sides to optimise the performance of the window opening and, where the wall construction allows, the system can also be configured to accommodate a fly screen recessed on three sides.‎ The front rebate is available in 72 mm or 54 mm configurations, with an 80 mm recessed fourth side fitted with a dedicated thermal break.‎ TECHNICAL SPECIFICATIONS: The system is made from EPS Neopor (sintered expanded polystyrene with added graphite) with a density of 30 kg/m³ and a declared thermal conductivity of λD = 0.‎030 W/mK.‎ The top cross-member and side walls consist of an 18 mm plywood load-bearing structure, integrated with EPS Neopor®, which ensures high insulation performance and excellent structural stability.‎ The system is designed to accommodate window frames fitted either flush with the internal wall or centred, thanks to the inclusion of an 18 mm wooden sub-frame, which ensures precise installation and secure fixing of the window frame.‎ The TBK SINGOLO BASIC 90 thermal insulation side walls, with a thickness of 90 mm and a depth that varies according to the project, ensure the continuity of the insulation around the window opening and help to reduce thermal bridges, thereby improving the energy efficiency of the building envelope.‎ The fourth TBK Type 80 thermal insulation side panel, made from high-density XPS, completes the window assembly by eliminating the lower thermal bridge.‎ The special trough-shaped design facilitates assembly with the side jambs and is designed to accommodate the window sill.‎ The system is supplied with a dedicated thermal break made from XPS for windows and from Purenit for French windows.‎ The system can be supplemented with numerous optional extras, including provision for a recessed fly screen via a special aluminium profile and the TBK skim-coat system, comprising external wall insulation mortar, a plaster-reinforcing mesh and technical PVC profiles to ensure professional installation and a finish that blends seamlessly with the façade.‎ THERMAL PERFORMANCE Linear thermal transmittance of the jamb (Ψ): 0.‎000 W/(mK) without external insulation and 0.‎019 W/(mK) with external insulation, in accordance with UNI EN ISO 10211.‎ Linear thermal transmittance of the fourth side (Ψ): 0.‎044 W/(mK) without external insulation and 0.‎17 W/(mK) with external insulation, in accordance with UNI EN ISO 10211.‎ THERMOBLOK® is the professional range of prefabricated thermal insulation monoblocks for window openings, designed and patented by TBK to offer a comprehensive, efficient and bespoke solution for window and door installation.‎ Drawing on experience gained in the window opening sector, the THERMOBLOK® range allows all the functional elements of the window opening – roller shutter box, side jambs, fourth side and accessories – to be integrated into a single system, ensuring continuous insulation and effectively reducing thermal bridges.‎ THERMOBLOK® is designed and manufactured to measure, according to the building’s characteristics, the wall’s construction and the specific requirements of the building site.‎ This bespoke design ensures high performance, simplified installation and seamless integration with the building system.‎ The range includes various configurations to meet a wide variety of design requirements, whilst maintaining the same high quality standards in terms of thermal insulation, durability, construction precision and ease of installation.‎ Why choose THERMOBLOK® A system designed and patented by TBK.‎ Fully bespoke monoblocks.‎ Reduction of thermal bridges around the window opening.‎ Integration of the roller shutter box, side panels, fourth side and accessories into a single system.‎ Suitable for both new builds and energy-efficiency refurbishment projects.‎ Solutions that can be customised to meet the architectural and performance requirements of the project.‎ High-quality construction and ease of installation.‎ THERMOBLOK® is TBK’s solution for creating a high-performance window opening, combining energy efficiency, build quality and maximum design freedom.‎ Further info from manufacturer on THERMOBLOK® – Singolo BASIC TBK
