TSP - Сварочный аппарат IT 2002

IT 2002 is an arc welding machine, particularly suitable for sheet metal thicknesses from 2 mm and thicker, for welding of anchors/pins, for direct on-site applications and for welding through intermediate sheets.‎ Microcontroller, function monitoring, stroke test, library function, process monitoring and RS232 interface.‎ Welding frequency: from dia.‎ 22 = 6 pins/min.‎ General Information Applications - Particularly suitable for sheet thicknesses ≥2 mm - Particularly suitable for welding of anchors/pins and on-site applications - Suitable for welding through intermediate sheets Process variants - Short-cycle arc welding - Rotary arc welding (MARC) Equipment - Welding with ceramic ferules (standard) - Welding with shielding gas (optional) Advantages Features - Microcontroller - for precise process timing, optimum functional reliability and maximum operating convenience - Function monitoring - automatic function test after switch-on; monitoring of all internal system functions - Stroke test - for gun with lift-off and welding heads - Library function - automatic voltage specification based on pin diameter selection within the welding range (with and without shielding gas); fine tuning via arrow keys Structure - Extremely easy to use - Compact - Mobile - high mobility due to compact size and light weight (50% weight saving compared to conventional units) - Robust - metal structure resistant to work in the factory or on the construction site Safety - With integrated mains filter (protected against voltage fluctuations) - Ideal for workplaces with large fluctuations in the main voltage - can also be used with critical voltage fluctuations (- 10% + 10%) - EMC test - Recording of voltage peaks during welding - Restart block - prevents welding on an already welded element - Transformer thermal monitoring - automatic shutdown in the event of overheating - Temperature regulated by a fan - reduces noise and dust in the welder (increased system reliability) - The control unit is galvanically separated from the welding lines - high degree of functional safety - Excellent protection against external interference - IP 23 degree of protection - Also allows work outdoors Welding - Display - infinite current settings; easy monitoring of all functions via bright LEDs; easy to use thanks to membrane keypad and digital display; adjustment of welding parameters, programs, shielding gas, process monitoring and automation possible; digital display of current, welding time and gas pre-flow (optional: pneumatic feed time for automation); separate adjustments for current and welding time - Powerful - built-in current reserves - Problem-free change of voltage polarity by reconnecting welding current and ground cables (polarity reversal) - Welding quality - very high arc stability even with low welding current - High process flexibility the high frequency (30 kHz) of the welding machine allows dynamic adjustments of the welding process Suitable welding guns and welding heads - A 12, CA 08 - A 16 - A 22 - A 25 - AI 06
