TSP VBZ-3 - Автоматическая сварочная машина

Automatic studfeederVBZ-3 is a fast, fully automatic stud feeder for welding flange studs in accordance with standard standards.‎ Length from 8 to 50 mm (without modification), feeder cup with special coating to reduce abrasion and noise.‎ Pin diameter: M3 to M8, dia.‎ 3 to 8 mm (other diameters on request) Feed rate: up to 30 pins/min (depends on welding element and feed tube) Applications - Automatic studfeeder VBZ-3 for automatic and fast feeding of welding elements with flange according to current standards - Automatic feeding of welding elements from dia.‎ 3 to dia.‎ 8 mm (with flange); (other diameters on request) - Length 8 to 50 mm (without feeder rebuild) Options - Additional air regulation via a valve is possible; this allows ideal regulation of the air flow required by the different diameters of the solder elements - Special feeding units on request Advantages Features - Specially coated feed cup, to reduce abrasion and noise - Air is controlled by pulses, there is no permanent air waste Structure - Quick and easy changeover for different weld element diameters (with quick-change system) - Control integrated in the structure - All connections are located on the front panel for fast operation - Compressed air can be individually adjusted from the front panel of the VBZ-3 for best feeding performance - The air holder is sealed on the rail by a valve to allow easy orientation of the soldering elements - The plastic cover allows easy inspection of the soldering elements to be fed - Modular construction easy to use Safety - The mains filter is integrated to allow better electrical protection
