VMZINC® COMPACT - Изолированная металлическая панель для крыши

VMZINC® COMPACT is a warm roofing system that can be used for new buildings or renovations, and is suitable for trapezoidal sheet metal load-bearing elements in steel, concrete and wood.‎ It is based on the construction of a roof complex without mechanical through-fixing.‎ The VMZINC® Roof Compact system combines: a double seam QUARTZ-ZINC PLUS covering and FOAMGLAS® cellular glass insulation.‎ Packaging: slabs to be profiled or already processed on request.‎ VMZINC Roof is recommended for buildings with a very high hygrometric coefficient.‎ Advantages - Total water vapour proofing: ideal system for buildings with a very high hygrometric coefficient  - No mechanical through-anchorage: no risk of thermal bridges or corrosion of the fasteners  - VMZINC® Zinc plus® titanium zinc laminate with protective lacquer on the underside  Applications - Corrugated steel sheets  - Reinforced concrete or hollow-core concrete  - Continuous wooden substrates in planks or panels  - Any shape, except concave curves  - Inclinations from 5% (3°) to 170% (60°) - Convex curved roofs with inclinations < 3° (please consult VMZINC Roof Technical Department)  Any climatic condition.‎ Depending on the climatic zone, we recommend that you follow the guidelines provided by VMZINC.‎ Characteristics Authorised substrates Corrugated steel sheets Cement  Solid wood or wood-derived panels.‎ Climates Any climate.‎ Double seam fixing clips VMZINC clips fixed to galvanised steel plates by means of "SPEDEC" (SFS) screws supplied by VMZINC.‎ Separator layer Geotextile type (minimum 100 g/m²).‎ Products type: - Sarnafil TU108-05 - Dorken Delta Fol Pve Bitumen sheath Bitumen-elastomeric reinforcedsheathing, normal use, laid head to head.‎ Non-through anchorage plates Made of galvanised steel measuring 150 x 150 mm and 1 mm thick, hot-bonded into the insulating substrate to act as an anchorage point for the VMZINC® Zinc plus® cladding fixing clips.‎ Load-bearing insulation Foamglas® T4  Cellular glass sheet (aluminium-silicate), incompressible and with vapour barrier function.‎ Dimensions 60 x 45 cm, variable thickness (depending on the thermal insulation required).‎ System description Areas ofapplication Roofing of rooms with a high or very high hygrometric coefficient (e.‎g.‎ swimming pool).‎ Flat roofing with a slope ≥ 5% and ≤ 60% In the case of curved convex roofing with slopes < 5%, please consult our offices.‎ Concave roofing excluded.‎ Advantages - Warm roofing system combining a double standing seam VMZINC Roof and FOAMGLAS insulation.‎ - Total water vapour impermeability system ideal for buildings with a very high hygrometric coefficient.‎ - The absence of mechanical through-fixing reduces integrated thermal bridges.‎  - VMZINC® Zinc plus (patented): zinc with protected underside.‎
