LAMIA - Сдвижная регулируемая алюминиевая солнечная защита

LAMIA is a sliding aluminium sunshade with slats from 20 to 150 mm, fixed or adjustable, that can be applied to existing bioclimatic pergolas and new wall or ceiling structures.‎ Dynamic light control, thermal comfort and freedom of façade design in a single system: LAMIA transforms solar shading into an active design element, capable of modulating shade, ventilation and privacy without sacrificing architectural language.‎ Aluminium sliding sunshade, works with side sliding leaves on a double guide - upper with adjustable pivot carriages, lower with anti-slip seal - 120 kg capacity per leaf and configurations from one to ten leaves.‎ The slats, 20-150 mm wide with a rectangular, square or ellipsoidal section, are fixed, adjustable or mixed on the same frame: a compositional freedom that is difficult to find elsewhere.‎ Installation, wall or ceiling mounted, is also possible as a retrofit on existing bioclimatic pergolas.‎ Technical characteristics Profile material: extruded aluminium alloy EN AW-6060 with aluminium frame brackets Slats: 20-150 mm wide, rectangular, square or ellipsoidal cross-section Slat type: fixed, adjustable or mixed on the same system Sash sizes: width 600-1,500 mm, height 1,500-3,500 mm (up to 4,000 mm on request) Configurations: 1-5 sashes with side opening, 6-10 sashes with central opening Sliding system: S120 double-guide kit - upper with two adjustable pivot carriages and releasable flat bracket for easy disassembly, lower with anti-slip seal, load capacity 120 kg per sash.‎ Mechanical components in stainless steel or galvanised steel Colours and finishes: full RAL range in gloss, matt or wrinkled finish.‎ Standard colours including Pure White 9010, Anthracite Grey 7016, Moss Green 6005, Chocolate Brown 8017, Brilliant Aluminium 9006, Rusty Corten, Painted Bronze Motorisation: manual operation as standard, optional motorisation via radio control integrable accessories: LED lighting integrated in the frame Certifications: CE marking in accordance with EN 1090, NTC 2018 structural calculation for wind and snow zones Applications Residential: terraces, loggias, gardens and villas with customisable, made-to-measure shading HoReCa: dehors of restaurants, bars and hotels - extend the outdoor season with comfort Architectural contract: offices, hotels, retail and high-profile hospitality facilities Retrofit: integration on existing bioclimatic pergolas, also from other manufacturers
